Overview

Supported Categories

  • MEP Fabrication Hangers
  • Generic Models

Revit Family

  • eV_Point
This point family also contains the APL point family
  • Centerline Point
  • Control Point
  • Layout Point
  • Rectangular Sleeve Point
  • Round Sleeve Point
The Family "eV_Point", can be embedded into any traditional Family of which you wish to collect point locations from.

Fabrication Hangers - Exporting Format

  1. CSV Format
  • Point Name - Item Number + eVolve Data
  • X Coordinate
  • Y Coordinate
  • Z Coordinate
  • Description - Rod Dia + Supported Size + Service Abbreviation + Item Description
  1. TFL Format
  • Point Name - Item Number + eVolve Data
  • X Coordinate
  • Y Coordinate
  • Z Coordinate
  • Description - Rod Dia + Supported Size + Service Abbreviation + Item Description
  • Layer - Fabrication Service Name

Families - Exporting Format

  1. CSV Format
  • Point Name - Point Number
  • X Coordinate
  • Y Coordinate
  • Z Coordinate
  • Description - Fabrication Service Abbreviation + Point Description
  1. TFL Format
  • Point Name - Point Number
  • X Coordinate
  • Y Coordinate
  • Z Coordinate
  • Description - Fabrication Service Abbreviation + Point Description
  • Layer - Fabrication Service Abbreviation
